Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 870 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
I
2
C bus control register 1 ICCR1 8 H'A447 0000 IIC2 8
I
2
C bus control register 2 ICCR2 8 H'A447 0001 8
I
2
C bus mode register ICMR 8 H'A447 0002 8
I
2
C bus interrupt enable register ICIER 8 H'A447 0003 8
I
2
C bus status register ICSR 8 H'A447 0004 8
I
2
C bus slave address register SAR 8 H'A447 0005 8
I
2
C bus transmit data register ICDRT 8 H'A447 0006 8
I
2
C bus receive data register ICDRR 8 H'A447 0007 8
NF2CYC register NF2CYC 8 H'A447 0008 8
— — — —
Compare match timer start register_0 CMSTR_0 16 H'A44A 0000 CMT 16
Compare match timer control/
status register_0
CMCSR_0 16 H'A44A 0004 16
Compare match counter_0 CMCNT_0 16 H'A44A 0008 16
Compare match timer constant register_0 CMCOR_0 16 H'A44A 000C 16
Compare match timer start register_1 CMSTR_1 16 H'A44B 0000 16
Compare match timer control/
status register_1
CMCSR_1 16 H'A44B 0004 16
Compare match counter_1 CMCNT_1 16 H'A44B 0008 16
Compare match timer constant register_1 CMCOR_1 16 H'A44B 000C 16
— — — —
Timer control register_3 TCR_3 8 H'A449 0000 MTU 8/16/32
Timer control register_4 TCR_4 8 H'A449 0001 8/16/32
Timer mode register_3 TMDR_3 8 H'A449 0002 8/16/32
Timer mode register_4 TMDR_4 8 H'A449 0003 8/16/32
Timer I/O control register H_3 TIORH_3 8 H'A449 0004 8/16/32
Timer I/O control register L_3 TIORL_3 8 H'A449 0005 8/16/32
Timer I/O control register H_4 TIORH_4 8 H'A449 0006 8/16/32
Timer I/O control register L_4 TIORL_4 8 H'A449 0007 8/16/32
Timer interrupt enable register_3 TIER_3 8 H'A449 0008 8/16/32
Timer interrupt enable register_4 TIER_4 8 H'A449 0009 8/16/32
Timer output master enable register TOER 8 H'A449 000A 8/16/32
