Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 886 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
DMAOR — — CMS1 CMS0 — — PR1 PR0 DMAC
— — — — — AE NMIF DME
— — — — — — — —
— — RC0 RC1 RC2 RC3 — —
DMARS0 C1MID5 C1MID4 C1MID3 C1MID2 C1MID1 C1MID0 C1RID1 C1RID0
C0MID5 C0MID4 C0MID3 C0MID2 C0MID1 C0MID0 C0RID1 C0RID0
DMARS1 C3MID5 C3MID4 C3MID3 C3MID2 C3MID1 C3MID0 C3RID1 C3RID0
C2MID5 C2MID4 C2MID3 C2MID2 C2MID1 C2MID0 C2RID1 C2RID0
SDIR T17 T16 T15 T14 T13 T12 T11 T10 H-UDI
— — — — — — — —
SDIDH DID31 DID30 DID29 DID28 DID27 DID26 DID25 DID24
DID23 DID22 DID21 DID20 DID19 DID18 DID17 DID16
SDIDL DID15 DID14 DID13 DID12 DID11 DID10 DID9 DID8
DID7 DID6 DID5 DID4 DID3 DID2 DID1 DID0
ICCR1 ICE RCVD MST TRS CKS3 CKS2 CKS1 CKS0 IIC2
ICCR2 BBSY SCP SDAO SDAOP SCLO — IICRST —
ICMR MLS — — — BCWP BS2 BC1 BC0
ICIER TIE TEIE RIE NAKIE STIE ACKE ACKBR ACKBT
ICSR TDRE TEND RDRF NACKF STOP AL/OVE AAS ADZ
SAR SVA6 SVA5 SVA4 SVA3 SVA2 SVA1 SVA0 FS
ICDRT
ICDRR
NF2CYC — — — — — — — NF2CYC
CMSTR_0 — — — — — — — — CMT
— — — — — — — STR
CMCSR_0 — — — — — — — —
CMF — CMR1 CMR0 — — CKS1 CKS0
CMCNT_0
CMCOR_0
