341

Chapter 26 DMA Controller

2.DMA Controller (DMAC) Registers

10110 0100 70 USART (LIN) 11 RX available

10111 0100 71 USART (LIN) 11 TX -

11000 0100 72 USART (LIN) 12 RX available

11001 0100 73 USART (LIN) 12 TX -

11010 0100 74 USART (LIN) 13 RX available

11011 0100 75 USART (LIN) 13 TX -

11100 0100 76 USART (LIN) 14 RX available

11101 0100 77 USART (LIN) 14 TX -

11110 0100 78 USART (LIN) 15 RX available

11111 0100 79 USART (LIN) 15 TX -

10000 0101 80 Input Capture 0 -

10001 0101 81 Input Capture 1 -

10010 0101 82 Input Capture 2 -

10011 0101 83 Input Capture 3 -

10100 0101 84 Input Capture 4 -

10101 0101 85 Input Capture 5 -

10110 0101 86 Input Capture 6 -

10111 0101 87 Input Capture 7 -

11000 0101 88 Output Compare 0 -

11001 0101 89 Output Compare 1 -

11010 0101 90 Output Compare 2 -

11011 0101 91 Output Compare 3 -

11100 0101 92 Output Compare 4 -

11101 0101 93 Output Compare 5 -

11110 0101 94 Output Compare 6 -

11111 0101 95 Output Compare 7 -

10000 0110 96 Programmable Pulse Generator 0 -

10001 0110 97 Programmable Pulse Generator 1 -

10010 0110 98 Programmable Pulse Generator 2 -

10011 0110 99 Programmable Pulse Generator 3 -

10100 0110 100 Programmable Pulse Generator 4 -

10101 0110 101 Programmable Pulse Generator 5 -

Table 2-2 Settings for Extended Transfer Request Sources

IS EIS RN Function Transfer stop request
