DEFINITY Enterprise Communications Server Release 6
Maintenance for R6vs/si
555-230-127
Issue 1
August 1997
Maintenance Object Repair Procedures
Page 10-280CLSFY-PT (Call Classifier Port)
10
Tone Detection Verification Test (#42)
This test checks out each port in both the touch-tone receiver mode and in the
R2-MFC tone detection/generation mode. During the first half of the test, the
touch-tone receiver mode is tested. In the second half of the test, each port is put
into the R2-MFC mode. During this portion of the test, each port’s ability to
accurately detect and generate all forward and backward MFC tones is verified.
1. D = Destructive; ND = Nondestructive
Table 10-92. TEST #42 Tone Detection Verification Test
Error
Code
Test
Result Description/ Recommendation
none ABORT The system was not able to allocate all the resources needed for this test
OR there was an Internal System Error.
1 ABORT The system could not allocate all the resources needed to test the tones.
1001 ABORT The system was unable to put the Call Classifier port in the appropriate
mode to test it.
1002 ABORT The system could not allocate time slots for the test connection. This
situation could occur when the system is heavily loaded. If the system is
not heavily loaded, then test the TDM-BUS via the test tdm [1|2]
command. Refer to the TDM-BUS (TDM Bus) Maintenance documentation
for details.
1. Retry the command at one minute intervals a maximum of five times.
2. If the test continues to abort, escalate the problem.
1003 ABORT The system could not allocate a Tone-Clock circuit pack for the test
connection. This situation could occur when the system is heavily loaded
or if a Tone-Clock circuit pack is not present in the port network when this
test is executed.
1. Verify the existence of a Tone-Clock circuit pack in the same port
network.
2. If a Tone-Clock circuit pack is missing, install one in the same port
network.
3. Allow approximately one minute for the Tone-Clock circuit pack
maintenance to run on the newly inserted Tone-Clock circuit pack.
4. Retry the command at one minute intervals a maximum of five times.
5. If the test continues to abort, escalate the problem.
Continued on next page
