DEFINITY Enterprise Communications Server Release 5
Maintenance and Test for R5vs/si
555-230-123
Issue 1
April 1997
Maintenance Commands and Trouble-Clearing Aids
Page 8-192list marked-ports
8
Help Messages
If the system technician presses help after entering "list marked-ports" the
following message will be displayed:
[’print’ or ’schedule’]
Error Messages
If during the execution of a command a resource problem occurs that requires
the user to restart the command, then the following message will be displayed:
Command resources busy; Press CANCEL to clear, and then resubmit
If all of the available maintenance resources are currently in use, then the
following message will be displayed:
All maintenance resources busy, try again later
Output
For the following output example, the command entered was "list marked-ports."
Feature Interactions
None.
Port The port address (cabinet-carrier-slot-circuit) of the marked port.
Board-Type The type of circuit pack containing the marked port. If this circuit pack
information is no longer available because the circuit pack was
removed after the port was marked, the Board-Type field will be blank.
list marked-ports
MARKED-PORT INFORMATION
Port Board-Type
1C0101 DIG-BD
1C0601
1C0702 DIG-BD
Command successfully completed
